AKAI AM-2350 Stereo Integrated Amplifier and AKAI CS-703D Stereo Cassette Deck (1979)
AKAI AM-2350 Stereo Integrated Amplifier
Specifications
Power output: 35 watts per channel into 8Ω (stereo)
Frequency response: 20Hz to 20kHz
Total harmonic distortion: 0.2%
Damping factor: 30
Input sensitivity: 3mV (MM), 150mV (DIN), 150mV (line)
Signal to noise ratio: 75dB (MM), 95dB (line)
Channel separation: 50dB (MM), 55dB (line)
Output: 150mV (line), 30mV (DIN)
Speaker load impedance: 4Ω to 16Ω
Semiconductors: 16 x transistors, 13 x diodes, 2 x IC
Dimensions: 380 x 123 x 241mm
Weight: 7kg
AKAI CS-703D Stereo Cassette Deck (1979)
Specifications
Type: 2-head, single compact cassette deck
Track System: 4-track, 2-channel stereo
Tape Speed: 4.76 cm/s
Heads: 1 x record/playback, 1 x erase
Motor: electronically speed controlled DC
Tape Type: type I, CrO2
Frequency Response: 40Hz to 15kHz (Cr02 tape)
Signal to Noise Ratio: 56dB
Wow and Flutter: 0.06%
Total Harmonic Distortion: 2%
Input: 70mV (line), 0.25mV (mic)
Output: 0.41V (line)
Dimensions: 380 x 150 x 266mm
Weight: 5.1kg
Finish: black or silver front panel
Technics SA-818 AM/FM Stereo Receiver
Technics SA-818 AM/FM Stereo Receiver
Tuning range: FM, MW
Power output: 110 watts per channel into 8Ω (stereo)
Speaker load impedance: 4Ω to 16Ω
Dimensions: 566 x 172 x 396mm
Weight: 18.5kg
I found his BIG BOY as you can see in the pics, the top and bottom cover were missing
but it was fully working, all light woking.
