Tuning range: FM, MW
Power output: 35 watts per channel into 8Ω (stereo)
Frequency response: 20Hz to 20kHz
Total harmonic distortion: 0.5%
Damping factor: 40
Input sensitivity: 2.5mV (MM), 200mV (DIN), 200mV (line)
Output: 150mV (line), 30mV (DIN)
Speaker load impedance: 4Ω (minimum)
Dimensions: 151 x 534 x 370mm
Weight: 9.6kg
Finish: rack mount
Year: 1977
These are very nice receivers that seemed to fly under the radar. I picked mine up a couple years ago with the veneered particle board in bad condition. When I remove particle board, all that silver made it looks Bland. I remove the metal casing sanded it down to the metal and painted it black. I replace the particle board with solid Walnut, and finished it with polyurethane. It's my favorite One of a Kind receiver, that I will always keep
ReplyDeleteI have mine in the same fashion as your and I love!
ReplyDeletegood job
I love the radio. It's full of people talking about waffles that sound DELICIOUS.
ReplyDeleteOne more thought: EDDIE CANTOR. Think about it.
ReplyDeleteMon premier récepteur,je l'ai adoré.
ReplyDelete
